| Quantity: | |
|---|---|
Model NO. | HOWO 6x4 Dump Truck |
Power | Diesel |
Emission Standard | Euro 3 |
Engine Capacity | >8L |
Horsepower | 351-450hp |
Tire Design | Tubeless |
Condition | Used |
Cargo Tank Length | 5.3-6.2m |
Tire | 1200r20 |
Transmission | Hc16 |
Specification | 10500*2500*3450mm |
Origin | China Shandong |
Transmission Type | Manual |
Load Capacity | 31-40t |
Drive Wheel | 6×4 |
Seats | ≤5 |
Tire Certification | ECE,ISO |
Dumping Type | Front Lifting Style |
Cargo Tank Dimension | 7800*2300*1500mm |
Engine | Wd615.47 |
Cab | Hw76 |
Transport Package | Export Packing |
Trademark | howo |
Production Capacity | 10000PCS/Month |
Dump trucks are mainly used for transporting bulk and stackable goods (such as sand, soil, ore, and crops), as well as for transporting packaged goods. Therefore, dump trucks mainly serve building materials factories, mines, construction sites, etc. In order to improve transportation productivity, dump trucks are usually used in conjunction with loaders, excavators, belt conveyors, etc. to achieve full mechanization of transportation. The mass utilization coefficient of dump trucks is low, making them suitable for short distance transportation to fully leverage the advantages of unloading mechanization.
Truck Brand | SINOTRUK -HOWO |
Driving Style | Left Hand Driving or Right hand Driving |
Cargo body size (L*W*H, mm) | 9400×2300×1000mm |
Cargo thickness(mm) | Bottom:8, Side:6mm |
Lift type of Carriage | FRONT LIFT |
Loading Weight(T) | 25--70 |
Fuel type | Diesel |
Horse Power | 250-450HP |
Emission | EURO II or EURO III |
Engine Model | WD615,water-cooled,four strokes,6 cylinders in line with water |
Transmission | HW15710,10 forwards and 2 reverse |
Steering system | ZF8118hydraulic steering with power assistance |
Front axle | HF9 , Steering with double T-cross section beam |
Rear axle | HC16, Pressed axle housing, central double reduction with differential |
Tyre | 12.00-20 |
Tires quantity | 10+1 spare |
With a manual transmission, which may be in 12 or more gears, the high torque transfer capability ensures the right power distribution in all conditions.
Rear Axle: The enhanced two-stage reduction bridge or single-stage reduction bridge is equipped with a large tonnage main reduction ratio to meet the needs of heavy climbing and provide reliable carrying capacity.
Engine: Usually equipped with large displacement, high-power diesel engines, such as Cummins, Weichai, and other well-known brand products, the power range may be 300 horsepower to more than 500 horsepower
Cab: Spacious and comfortable cab, wide vision, shock-absorbing seat, air conditioning, multi-functional steering wheel.
Container type: Common U-shaped bucket, rectangular bucket or rollover type, etc., the material is wear-resistant steel, internal spray anti-stick material to prevent goods from sticking. The volume of the cargo box can reach dozens or even hundreds of cubic meters according to the different models.
Chassis: Designed for heavy loads, the thickened stringer, beam and enhanced suspension system guarantee stability and durability under heavy loads. Suspension: The front axle adopts low-blade spring or air suspension, and the rear axle adopts multi-blade spring suspension, taking into account the bearing capacity and driving comfort.
